Product Introduction
The electric passenger and cargo tricycle is a freight tricycle. It uses lithium batteries. The overall style: the main body of the vehicle is bright red, with high visual recognition; the cockpit and cargo compartment adopt a new design with clear functional division. Cockpit: equipped with windshield, lights, and rearview mirrors to ensure basic driving vision and safety; the cabin is small and compact, suitable for single/double short-distance driving scenarios. The electric passenger tricycle adopts an open cockpit + green tarpaulin covering, the bottom of the cabin is flat, and metal guardrails are set on both sides, taking into account the convenience of loading and unloading and the need to limit cargo.
Production Details
The side of the compartment of the adult cargo tricycle adopts locking devices and related structures. These devices ensure that the passenger transportation space is sealed and safe. Ensure the personal safety of passengers
The overall welded box-shaped compartment is matched with a stainless steel bottom plate. This structure has high impact resistance, excellent acid and alkali corrosion resistance, and extends the service life of the compartment.
With green canvas, sufficient waterproof and sun protection, the service life of the vehicle is extended.
Product Features and Applications
Features
Independent cab design
Removable roof
Cargo compartment can carry passengers
Driver's seat with music player
Can be equipped with charger
Applications
● Long-haul trucking
● Agricultural product transportation
● Adult transportation
● Passenger protection
DUNYA Product Parameters
| Customer demand for heavy-duty electric three-wheeled trucks | |
| Cab | Semi-enclosed (tube frame tent) |
| Car body width | Width: 1.40m; Length: 2.3m |
| Vehicle load | 1500kg~2200kg |
| Speed | ≥50 km/h |
| Climbing slope | ≥25° |
| Factory base | |
| Vehicle model | AH2500DZH-A heavy-duty truck |
| Frame size: | 40*80*2mm integrated frame |
| Carriage size | 2200*1350*420mm steel plate compartment, bottom plate thickness 1.5mm |
| Pipe frame canopy |
Width: 980mm Length: 1100mm With waterproof backrest, electric wiper |
| Motor rated power | 72V3500W-magnetic encoding motor |
| Controller specifications | 3500W magnetic encoding controller |
| Tire size | Front and rear wheels: 500-12-10P |
| Front and rear wheelbase | 2450 |
| Braking mode | Drum brake-220 |
| Vehicle load | 900-1600kg |
| Vehicle weight | |
| 40 full container loading quantity | Loading method: semi-loose |
| Battery parameters and price | |
| Battery specifications | 72V150AH (BMS-Jiabaida) |
| Charger specifications | 10A |
| Charging time | Slow charging: 8-10 hours |
| Battery life | 2000 times, charge and discharge |
| Free warranty | We implement the after-sales buyout system: for every 200 sets of batteries, we will give you one set of batteries of the same model and three protection boards. We also provide a more convenient maintenance environment and corresponding spare parts. |
| Maximum speed | ≥45 km/h |
| Loaded mileage | ≥80㎞ |
| Unloaded mileage | ≥120㎞ |
| Battery parameters and price | |
| Battery specifications | 72V150AH (BMS-Jiabaida) |
| Charger specifications | 15A |
| Charging time | Slow charging: 8-10 hours |
| Battery life | 2000 times, charge and discharge |
| Free warranty | We implement the after-sales buyout system: for every 200 sets of batteries, we will give you one set of batteries of the same model and three protection boards. We also provide a more convenient maintenance environment and corresponding spare parts. |
| Maximum speed | ≥45 km/h |
| Loaded mileage | ≥100㎞ |
| Unloaded mileage | ≥150㎞ |
Product Qualification
The factory has planned a dedicated assembly line, which is specifically divided into operating positions such as frame assembly, power system integration, cockpit assembly, and final vehicle debugging. At the first station of the assembly line, the frame is first positioned and fixed, and then the chassis components such as suspension and brakes are assembled in sequence. The assembly process is as follows: At the power system station, the engine (drive motor for electric models) and battery pack are installed on the frame. At the same time, the wiring harness and pipeline laying work is carried out (fuel pipelines are laid for fuel tricycle models, and circuit pipelines are laid for electric tricycle models). Then, at the cockpit station, the cockpit structure that has been welded and painted is combined and installed with the frame with the help of connectors (such as bolts, brackets, etc.). After that, the cockpit cover, locks, and hydraulic support columns (if the model is equipped with automatic loading and unloading functions) and other parts are assembled. The remaining stations are responsible for operations such as tire installation, headlight assembly, and seat fixing. The assembly of the entire vehicle is completed through the orderly advancement of each link.
