Product Introduction
Designed for heavy-duty transport needs, this electric cargo tricycle is equipped with a powerful Loncin 150cc air-cooled single-cylinder four-stroke engine with a rated power of 8.2kW and a torque of 10.0N·m. It is designed to balance performance and fuel economy (≤354g/kw·h) and is equipped with dual start functions (electric start and kick start) for greater convenience.
The frame is reinforced with a 40×60mm heavy-duty steel chassis, with a rear track of 870mm, a wheelbase of 1100mm, a tire specification of 4.5-12, and a ground clearance of 160mm, ensuring stability and controllability even on rugged terrain. Both front and rear drum brakes provide reliable braking force, and a payload capacity of 500-700kg enables heavy-duty cargo transportation.
The dual front shock absorbers and five-leaf spring rear suspension system improve ride comfort and effectively reduce driving fatigue. Designed to handle a variety of harsh road conditions, this electric cargo tricycle ensures excellent performance in urban, rural and off-road conditions.
With a top speed of 60 km/h or more and an optional 12-liter fuel tank, it can provide a longer range for transportation. This electric cargo tricycle strikes a perfect balance between performance, efficiency and cost.
Production Details
Product Features and Applications
Applications：
After more than 10,000 kilometers of driving on bumpy roads, the frame structure of this three-wheeled vehicle with passenger seats still maintains its original integrity without any signs of cracks or bending. It can withstand wind speeds of up to 80 km/h without damage, and when a 1 kg steel ball is dropped on the windshield from a height of 2 meters, the glass only has slight scratches instead of shattering, ensuring the safety of the rider and passengers.
DUNYA Product Parameters
| SUSPENSION | Design Max Speed | ≥60 km/h |
| Loading Capacity | 500-700 kg | |
| Gross Weight | 380 kg | |
| Dimension(L*W*H) | 3350x1250x1450mm | |
| Cargo size(L*W*H) | 1800*1250*1450mm | |
| Battery | 9A | |
| Front Wheel Brake | Drum | |
| CHASIS ( FRAME) | Keel (mm) | 50*70 strong chasis |
| Track | 870 mm | |
| Wheel Base | 1100 mm | |
| Ground Clearance | 170mm | |
| Tire | 5.0-13 | |
| SHOCK | Brake Operation Mode(F/R) | Drum |
| Front suspension | Double Front shock absorber | |
| Rear suspension | Leaf spring 5(3+2) pieces | |
| Transmission Type | Shaft Drive | |
| Rear axle | Car Strength Driving rear axle | |
| ENGINE | Engine Type | Single cylinder,4-stroke,camshaft downward, 360cc watercooling(optional) |
| Cool Type | Water Cooler | |
| Fuel Tank Capacity | 12 L(optional) | |
| Min.Fuel Consumption | <=354g kw.h | |
| Rated Power&Rotating Speed | 8.2kw/8500r/min | |
| Max.Torgue/Rotating Speed | 10.0N.m/7500r/min | |
| Lowest No-Load Speed Stability | 1500±150rpm | |
| Clutch Method | Manual-Hand | |
| Ignition System | C.D.I. | |
| Starter | Kick/Electric | |
| Transmission | 5 Forward &1 Reserse Gears | |
| PACKING | Loading Capacity (CKD) | 45 Units in 40"HQ |
| Delivery Time (from loading port) | 30-35 Days after receiving advance payment |
Product Qualification
Our products comply with ISO 9001:2008 quality standards and meet all China mandatory CCC certification requirements. With strong manufacturing capabilities, a reliable supply network and responsive after-sales service, we are committed to providing reliable, high-performance products to our global partners.
